Surge Protection 312J
Model
|
EP 2000 |
| Capacity |
2000 VA / 1200W |
| Input Voltage |
110 / 120 VAC or 220 / 230 / 240 VAC |
| Input Voltage Range |
81-145 VAC / 162-290 VAC |
| Input Frequence |
60/50 Hz (auto sensing) |
| Output Voltage |
±10% |
| Output / Frequence Range |
60 Hz or 50 Hz ±1 Hz |
| Output / Transfer Time (Typical) |
Typical 2-6 ms, 10ms max. |
| Output / Waveform (Batt. Mode) |
Simulated Sine Wave |
| Battery / Battery Type & Number |
12 V / 9 AH x 2 |
| Battery / Backup Time (One PC load@120W) 10% Load |
30 min. |
| Battery / Typical Recharge Time |
4-6 hours recover to 90% capacity |
| Indicators / Ac Mode |
The right green LED lighting & the 2nd to 5th green LEDs gradually lighting indicating load level |
| Indicators / Battery Mode |
The right green LED flashing & the 2nd to 5th green gradually lighting indicating battery capacity |
| Indicators / Fault |
Red lighting |
| Protection / Full Protection |
Overload, discharge and overcharge protection |
| Alarm / Battery Mode |
Sounding every 10 seconds |
| Alarm / Low Battery |
Sounding every second |
| Alarm / Overload |
Sounding twice per second |
| Alarm / Battery Replacement Alarm |
Sounding every 2 seconds |
| Alarm / Fault |
Continuously sounding |
| Outlet sockets |
Schuko x 3 + IEC x 3 / also provide India, French, Schuko, NEMA, and IEC for selections |
| Physical Dimension, D x W x H (mm) |
397 x 146 x 205 |
| Physical Net Weight (kg) |
11.5 |
| Operating Environment / Humidity |
0-90% RH @ 0-40°C (non-condensing) |
| Operating Environment / Noise Level |
Less than 40dB |
| Management / Optional USB / RS-232 Port |
Supports Windows® 98/2000/2003/XP/Vista/2008, Windows® 7, Linux, and MAC |
