| Kamera |
| Képérzékelő |
1/3” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Aperture |
2.8 mm: F1.6 |
| 4 mm: F1.6 |
| Optika |
4 mm |
| Lens Mount |
M12 |
| Min. szükséges megvilágítás |
Color: 0.04 Lux@F1.6; 0 Lux with IR |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Unified/ Scheduled/ Auto |
| Digital Noise Reduction |
3D DNR |
| WDR |
DWDR |
| IR Working Distance |
30m |
| Forgatási/döntési szög |
Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360° |
| Illumination Distance |
30m (LED) |
| Látószög |
(2.8 mm) Horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 122° |
| (4 mm) Horizontal FOV: 79°, vertical FOV: 43°, diagonal FOV: 93° |
| LENS |
| Type |
Fixed Focal Lens |
| Focal Length |
2.8/4 mm |
| Aperture |
2.8 mm: F1.6 |
| 4 mm: F1.6 |
| FOV |
2.8mm: |
| Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122° |
| 4mm: |
| Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° |
| Lens Mount |
M12 |
| DORI Distance |
2.8 mm |
| Detect: 64 m (209 ft) |
| Observe: 27 m (87 ft) |
| Recognize: 13 m (42 ft) |
| Identify: 6 m (21 ft) |
| |
| 4 mm |
| Detect: 80 m (262 ft) |
|
|
