| Video and Audio |
|
| IP Video Input |
16-Channel |
| Incoming Bandwidth |
80 Mbps |
| Outgoing Bandwidth |
60 Mbps |
| HDMI Output Resolution |
1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| VGA Output Resolution |
1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| Video Output Mode |
HDMI/VGA Simultaneous Output |
| Multi-View Display |
1/4/6/8/9/16 |
| DECODING |
|
| Audio Compression |
G.711A/G.711U/G.726 |
| Video Compression |
H.265+/H.265/ H.264+/H.264 |
| Record Resolution |
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ |
| |
2CIF/CIF/QCIF |
| Synchronous Playback |
16-Channel |
| Capability |
25fps: |
| |
2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
| |
|
| |
30fps: |
| |
4-ch @ 3MP, 2-ch @ 5MP |
| Record Management |
|
| Record Mode |
Manual Recording, Scheduling Recording, Motion Detection Recording |
| Playback Mode |
Instant Playback, Regular Playback, Tag Playback, Event Playback |
| Backup Mode |
Regular Backup, Video Clip Backup |
| Playback Function |
Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full |
| |
Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off |
| Hálózat |
|
| Szabvány |
UPnP (Plug and Play), NTP (Network Timing) |
| Mobile Phone Access |
Android, iOS |
| Web Browser |
Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability |
ONVIF, CGI |
Adatok
Max rögzíthető csatornák száma
Max rögzíthető IP kamera felbontás
Cikkszám
CE0BBIZVIGNVR2016H16P
